Please enter your contact below and click "SAMPLE QUOTES" to receive more information on the new Tektronix 4 Series B Mixed Signal Oscilloscopes.

  1. Models:
     MSO44B 4-BW-200
     MSO44B 4-BW-350
     MSO44B 4-BW-500

      MSO44B 4-BW-1000
     MSO44B 4-BW-1500
     MSO46B 4-BW-200


      MSO44B 4-BW-1000
     MSO46B 4-BW-350
     MSO46B 4-BW-500

     MSO46B 4-BW-1000
     MSO46B 4-BW-1500
  2. Notes:

Tektronix's New 4 Series B MSO
Adapts to virtually any testing challenge.

The 4 Series B MSO combines performance and analysis capabilities to address the vast majority of engineering challenges with an industry-leading intuitive user interface. The "B" version features a significantly faster processor system that speeds analysis and makes controls 2X more responsive. Full sample rate and record length are available on all channels, at all times. Each input channel can be used for synchronized analog waveform display and spectrum analysis or converted to 8 logic channels by connecting a logic probe for up to 48 digital logic channels. Powerful analysis and visualization tools, like FastFrame segmented memory, measurement and waveform histograms, and visual triggering are standard. It is available with a built-in 50 MHz arbitrary/function generator and decoding for over 25 serial protocols. Power analysis packages are also available to facilitate repeatable measurements on power supplies and 3-phase power converters. An array of available smart probes supports a wide range of applications. A 13.3-inch high-definition capacitive touchscreen with improved viewing angle, and an award-winning intuitive user interface make the 4 Series B MSO a pleasure to use.
Key Features
  • Bandwidths from 200 MHz to 1.5 GHz
  • 4 or 6 input channels
  • 6.25 GS/s sample rate
  • 12-bit ADCs
  • 31.25 or 62.5 Mpoints record length
  • Each channel can be used for synchronized analog waveforms and spectrum analysis, or converted to 8 logic channels
  • Industry-leading user interface
  • 13.3" HD touchscreen
  • Decoders available for over 25 serial protocols
  • Wide range of available probe



Recommended Instrument Options (See datasheet for full list)
  • 4-RL-1: Extend record length to 62.5 Mpoints/channel
  • 4-AFG: Add Arbitrary/Function Generator
  • 4-SREMBD: I2C and SPI decoding and triggering
  • 4-SRCOMP: RS232/422/485/UART decoding and triggering
  • 4-PWR: Advanced power measurements and analysis

Recommended Probes (See datasheet for full list)
  • TLP058
  • TMDP0200
  • THDP0200
  • TAP1500
  • TCP0030A
  • TPR1000
